Infrastructure

Infrastructure

List of Instruments

Sr. No.	Description	Make	Least Count	Size	Nos.
1	Surface Tester	Mitutoyo	0.001	--	1 Nos.
2	Digimatic Micrometer	Mitutoyo	0.001	0-25 mm / 25-50 mm	10 Nos.
3	Micrometer	Baker	0.001	50-75 / 75-100 / 100-125 mm	5 Nos.
4	Bore Gauge	Mitutoyo	0.001	10-18 / 18-35 / 35-60 / 50-150 mm	14 Nos.
5	Internal Dial Caliper	Teclock	0.01	20-35 / 30-62 / 55-153 mm	3 Nos.
6	Digital Height Gauge	Baker	0.010	0-300 mm	2 Nos.
7	Vernier Caliper	Mitutoyo	0.020	0-150 mm / 0-200 mm / 0-300 mm	3 Nos.
8	Digital Air Gauge Unit	Innovative	0.001	Single Channel	1 Nos.
9	Plunger Dial	Mitutoyo	0.001	0-1 mm	15 Nos.
10	Surface Plate	Luthra	--	900x600x150	1 Nos.
11	Magnetic V Block	Crystal	--	100x75x50	1 Nos.
12	Bench Center	Luthra	--	0-150 mm	1 Nos.

List of Machines

Sr. No.	Description	Make	Model	Control	Size	Nos.
1	CNC MACHINE	TSUGAMI	M08J-II	Fanuc Oi-TF	Chuck Dia. 200 mm, Length: 300 mm	1 Nos.
2	CNC MACHINE	LMW	LLT20TL5	Fanuc Oi-TC	Chuck Dia. 250 mm, Length: 500 mm	1 Nos.
3	CNC MACHINE	Daewoo	Lynx 210	Fanuc Oi-TB	Chuck Dia. 200 mm, Length: 350 mm	1 Nos.
4	CNC MACHINE	GLOBAL	NANO 200	Fanuc Oi-TF	Chuck Dia. 200 mm, Length: 300 mm	1 Nos.
5	VMC MACHINE WITH 4TH AXIS	PRECISION ENGINEERING TECHNOLOGIES	PVM 850	Fanuc Oi-MF PLUS	Table Size: 850 X 500 mm	1 Nos.

List of Machines

Sr. No.	Description	Make	Size	Nos.
1	ID & OD Grinding Machine	Smitson	OD 300mm & Length 1200mm	1 Nos.
2	ID & OD Grinding Machine	TOS	OD 400mm & Length 2000mm	1 Nos.
3	Surface Grinding Machine	Elb	Table 500 x 800 mm	1 Nos.
4	Surface Grinding Machine	Proth	Table 500 x 1500 mm	1 Nos.
5	CNC ID Grinding Machine	Rekha	ID 20 mm to 250 mm	1 Nos.
